Controls Multi-Function Display Screens
Screen Access
The multi-function display screens provide the following functionality:
•
• Displays operational status such as engine RPM, coolant temperature, service hours and system voltage.
Press button to scroll through screens/ selections.
Z • Press and hold button to access and select configuration functions.
• Displays error fault codes. • Configures displays settings. • Configures control options.
Fig. 7 – Multi-Function Display Interface Button
• Audible alerts for selected error conditions.
Press and release the multi-function display interface button (Z, Fig 7) to scroll through the status screens and any current error or maintenance required screens. Press and hold the interface button for 5 seconds to display the configuration selection screens and to select a particular setting (page 50).
Status, Maintenance and Error Code Screens Table 24: Status, Maintenance and Error Code Screens Screen
Access/Description
Status Screens Coolant Temperature Screen Default screen when no error codes are active. Press and release interface button (Z, Fig. 7) as many times as required to access this screen. Displays coolant temperature in “°F” or “°C”, depending upon units selected in Temperature Units Configuration screen (M). Engine RPMs Screen Press and release interface button (Z, Fig. 7) as many times as required to access this screen. Displays engine crankshaft revolutions per minute. Battery Voltage Screen Press and release interface button (Z, Fig. 7) as many times as required to access this screen. Displays battery charge in volts. Accumulated Service Hours Screen Press and release interface button (Z, Fig. 7) as many times as required to access this screen. Displays accumulated operation time in hours. Time accumulates when engine is running.
