Controls Switches/Indicators A
B
C
F
G
H
D
E
Fig. 6 – Switches/Indicators
Table 23: Switches/Indicators No
Item
A
Power-A-Tach®
Description Located on left panel. Press and hold bottom of switch to lock attachment onto the Power-A-Tach® quick attach system hitch; press and hold top of switch to unlock the attachment. See “Connecting/Disconnecting Attachments” on page 101. Press top of switch to apply parking brake. Press and hold top of switch to release parking brake.
B
Parking Brake
C
Heat/Air Conditioning (HVAC)
D
Front Windshield Wiper/Washer (option)
E
Rear Windshield Wiper/Washer
Indicator in switch is lit when parking brake is applied.
IMPORTANT: Parking brake is applied when either, or both, safety bar/ arm rests are in the raised position, operator is not in seat and door (if equipped) is opened. Located on left panel. See “Cab Heat and Air Conditioning (Option)” on page 59. Press bottom of switch to activate front windshield wiper; press and release top of switch to deactivate. Press and hold top of switch to operate front windshield washer spray. Indicator in switch is lit when front windshield wiper is activated. Press bottom of switch to activate rear windshield wiper; press and release top of switch to deactivate. Press and hold top of switch to operate rear windshield washer spray.
F
Auxiliary High-Flow Hydraulics
G
Self-Leveling Cancel (option)
Indicator in switch is lit when rear windshield wiper is activated. See “Auxiliary Hydraulics Operation” on page 104. Press top of switch to deactivate self-leveling; press bottom of switch to restore the self-leveling function.
Work Lights
Indicator in switch is lit when self-leveling is deactivated. Move switch to the middle position to activate the front work lights; press the top of switch to activate both the front and rear work lights; press bottom of switch to deactivate work lights. See “Work Lights” on page 65
H
Indicator in switch is lit when work lights are on.
