RBM20N2, RBM25N2
Service Manual
NOTE: You can also order the battery lock without the battery changing device for 2 batteries.
Figure 174. Battery changing device for 2 batteries overview
15.19.1 Remove an empty battery with the battery changing device for 2 batteries
NOTE: Before you use the battery changing device for 2 batteries, make sure that you adjust its height so that you can move the batteries between the truck and the battery changing device.
1. Park the truck in the battery changing area. 2. Set the power of the truck to OFF. 3. Disconnect the battery connector.
Copyright © 2018 by MCFE. All rights reserved.
Revision: A
Document ID: 633560-EN
730 (764)
