R E PA I R M A N U A L
MVT 628 T
REMOVING THE INTAKE AND DRAIN FILTER INTAKE FILTER
Fig. 8
- Raise the boom. - Remove the filter and the drain cap to empty the fluid tank completely. - Wash the tank thoroughly with kerosene, dry it and remove internal dirt. - Remove the filter element (Fig. 8). - Install a new filter element. - Completely refill the tank with hydraulic fluid.
HYDRAULIC SYSTEM FILTER (DRAIN)
Fig. 9
- Raise the boom. - Remove the filter cartridge (Fig. 9) and replace it with an original spare part.
Fig. 10 HYDROSTATIC SYSTEM FILTER (INTAKE) - Remove the protective guard - Remove the filter cartridge (Fig. 10). - Replace the cartridge full of fluid and replace it with an original spare part. - Start up the machine and leave the engine to idle at minimum rpm for 1-2 minutes. - Perform the first movements in both directions, keeping the engine at minimum rpm.
Page
29
