Transmission General : To work or dismantle the transmission form engine, first remove the bellow aggregate or assemblies.
Remove the transmission breather / dipstick for free flow of transmission oil.
1. Fender assembly 2. Hydraulic assembly 3. Electrical system. 4. Linkage, pipes & fittings 5. Three point Linkages 6. Seat assembly 7. Scuttle assembly
Breather / Dipstick
8. Steering assembly Jack the tractor with proper jack or hoist
Removal of Clutch Housing & Connection 1. Remove the bolts mounting the clutch housing to engine.
Jack Mounting Bolt
Loosen the bolts of the tyre & remove both the tyres.
2. Separate the engine form the clutch housing.
Loosen the drain the plug of the transmission & drain the transmission oil.
3. Remove the spring of clutch release sleeve & remove the clutch release sleeve with bearing.
Spring Clutch Release Sleeve
