INSTRUMENTS /CONTROLS ______________________________________________
5. CLUTCH PEDAL – The clutch must be disengaged when starting the engine, stopping the tractor, storing the tractor and operating the following levers,gear shift lever, range lever, rear PTO lever, MID PTO Lever, MFD lever creep lever. 5-1.
DUAL CLUTCH
Pedal has three positions as follows:
1. Pedal completely released – Transmission and PTO engaged 2. Pedal partially released - Transmission disengaged, PTO engaged 3. Pedal completely depressed – Transmission and PTO disengaged
6. CLUTCH LOCK LATCH – For long term storage, lock the clutch pedal in the disengaged position. This will prevent the clutch disc from sticking to the engine flywheel.
34
16 Series, Model - 2816 4WD
