FIELD OPERATION _____________________________________________________
REMOTE HYDRAULICS OPERATION (IF EQUIPPED) REMOTE HYDRAULIC CONTROL LEVER
Float Operation To operate the remote hydraulics in a float condition, move the control lever fully forward to the detent position. The lever will not return to neutral automatically when in the float position. IMPORTANT : If implement is attached that has single acting cylinders, always use the “FLOAT” position when lowering. Continual use of the “LOWER” position will cause overheating and possible damage to the hydraulic system. NOTE: The control lever for the remote hydraulic valve must be in the neutral for the three point hitch to operate. IMPORTANT: Never park a tractor with an implement in the raised position. Moving the control lever forward will lower the implement even though the engine is not running. If it is necessary to service the implement in the raised position, use jack stands to safely block the implement in place. Put the hydraulic flow control knob in the LOCK position.
69
16 Series, Model - 2216
