FIELD OPERATION _____________________________________________________
Draft Control Lever (If Equipped) DRAFT CONTROL LEVER
HEAVY
LIGHT
Draft control can be used to automatically lift and lower an implement to maintain a constant load through variable soil conditions. The amount of draft can be adjusted for the implement being used.
To select the correct position for the draft control lever, the tractor and implement must be operated in a field. STEP 1
STEP 3 STOPPER
DRAFT CONTROL LEVER LIGHT LOCK
DRAFT
HEAVY
Move the draft control lever rearward to select the correct position of the lever. If the implement is lifting up, move the lever forward. If the engine RPM is decreasing, move the lever rearward. The depth of the implement will be automatically controlled by the draft on the implement.
Lower the implement and rotate the stopper located on the top of the upper link bracket. STEP 2 HITCH CONTROL LEVER RAISE
LOWER
Slowly move the hitch control lever forward until the implement is at the needed depth. 65
16 Series, Model - 2216
