OPERATING INSTRUCTIONS ______________________________________________
WARNING LAMPS LAMP SWITCH
TURN SIGNAL SWITCH
FLASHER
CONTROL BUTTON
The lamp switch has three positions. Turn the switch clockwise to illuminate the head lamp, rear red lamp, and instrument panel lamps. Push the flasher control button down to operate the amber warning lamps. When the turn signal switch is moved upward to make a right turn, the RH warning lamp will illuminate ON and OFF and the LH lamp will illuminate continuously. When the turn signal switch is moved downward to make a left turn, the LH warning lamp will illuminate ON and OFF and the RH lamp will illuminate continuously. When the turn signal switch is returned to the center position, both warning lamps will illuminate ON and OFF. IMPORTANT: When towing an implement or wagon with the tractor, the complete rear area warning system (amber warning lamps, rear red lamp and SMV emblem) must be easily seen by any vehicle operator coming near the tractor.
56
16 Series, Model - 2216
