LUBRICATION/FILTERS/FLUIDS___________________________________________
Transmission Oil Change Oil Change Interval ............................................................ Every 200 hours To change the transmission oil, use the following procedure:
DRAIN PLUG
1. Put the tractor on level ground, apply the park brake and stop the engine. Move the range shift lever to L position. 2. Remove the drain plugs from the transmission case. NOTE: For best results, drain the oil when the oil is warm.
HYDROSTATIC DRIVE
3. Replace the hydraulic filter. See Hydraulic Filter in this manual. 4. Install the drain plugs with a seal washer and tighten to a torque of 39 to 44 Nm (29 to 33 lb ft). 5. Add the recommended oil through the fill hole and check the oil level. 6. Start the engine and check for leaks. FILL HOLE
7. Recheck the oil level after stopping the engine. If the oil level is low, add oil up to the specified level.
GEAR DRIVE
105
16 Series, Model - 2216
