LUBRICATION/FILTERS/FLUIDS___________________________________________
ENGINE LUBRICATION Service Specifications Oil Level Check Interval ....................................................................... Daily. Oil Change Interval ............................................................ Every 100 hours (See NOTE) Oil Type ............................................. See Lubrication Table in this manual. Oil Capacity – Without Filter Change ...................... 3.7 Litre (3.9 Quarts). With Filter Change ........................... 4.2 Litre (4.4 Quarts). NOTE: Change the engine oil after the first 50 hours of operation and then use the regular change interval. Change the engine oil more frequently when the operating conditions are severe, such as, operating under heavy load, starting and stopping with frequency, or operating in very high or very low ambient temperatures.
Engine Oil Level To check the engine oil level, put the tractor on level ground and stop the engine. Pull the dipstick out, wipe the dipstick with a dry cloth and fully install the dipstick to check the oil level. If the oil level is below the lower Notch, add oil to raise the oil level to the upper Notch. Do not raise the oil level above the upper Notch.
ENGINE OIL DIPSTICK
IMPORTANT : The level should be checked before starting or 5 minutes after the engine has been shut off. FULL
ADD
ENGINE OIL DIPSTICK
90
16 Series, Model - 2216
