Control, operation
Operating manual
Working with the machine
Setting stroke limitation: For a description, see chapter "Operator's menu", submenu "hbg max point". Application of stroke limitation:
Fig. 3-91
Operating elements of the stroke limitation function
Park the machine on level ground. Turn the key switch S249 to position 0. The stroke limitation function is activated. The following operating statuses are indicated on the display: S249
Display
Operating status
0
Stroke limitation on The stroke limitation function is activated. The working tool can only be lifted to the maximum permissible working height.
0
Stroke limitation, preliminary shut-down The preliminary shut-down function slows down the upward movement of the working attachment before the maximum permissible working height is reached (indicator light H159 on).
0
Stroke limitation, shut-down The shut-down point of the maximum permissible working height is reached.
0
Stroke limitation overridden The stroke limitation function is overridden so that the working attachment can be moved without restrictions.
Tab. 3-3
Operating status - display
copyright by
3 - 88
MJFCIFSS
A 312 Litronic / 11140216
