Control, operation
Operating manual
Working with the machine
Adjust the flow Super Finish settings, if necessary (see chapter "Operator’s menu", SF-Flow menu).
3.4.17
Attachments in continuous operation (optional equipment) This function allows for the operation of an attachment (e.g. mower rake). The function must first be activated.
Fig. 3-89
Operating elements for continuous mode operation
Preselecting continuous operation: The continuous mode is preselected with the switch S124. The working tool must be activated (S241), and servo control (S35) must be switched on. Press the switch S124. The indicator light in the switch is on. Continuous mode is now preselected. Switching attachment on/off: Continuous mode is activated/deactivated at the left joystick. Press the rocker switch S451 down. The indicator light H329 is on. The attachment is switched on (in continuous mode). Press the rocker switch S451 down. The indicator light H329 is off. The attachment is switched off. Continuous operating mode is also switched off in the following cases: – Servo control S35 is switched off. – The safety lever is moved up. – The working tool is deactivated (switch S241 off). – The ignition is switched off. Deactivating continuous mode: To terminate continuous mode operation, press the switch S124. The indicator light in the switch is off.
copyright by
3 - 86
MJFCIFSS
A 312 Litronic / 11140216
