OPERATION
DETAILED CONTROLS AND GAUGES
Maintenance display items are as follows: Monitor No. 01 02 03 04 05 06 07 08 09 10
Maintenance item Change engine oil Replace engine oil filter Replace fuel filter Replace hydraulic oil filter Replace hydraulic tank breather
Default set screen (H) 500 500 500 500 1000
Replace corrosion resistor Change PTC case oil Change final drive case oil Change swing machinery case oil
1000 1000 2000
Change hydraulic oil
5000
1000
If it is desired to change settings for the maintenance interval, have your Komatsu distributor change the settings. The method of checking time remaining until maintenance is as follows: 1. Look at the maintenance screen, press up switch (9) or down switch (10) on the monitor switch portion, and select the item. (Color of the monitor for selected item is inverted to black.)
2. After selecting the monitor item, press input confirmation switch (11). Display screen will switch to the time remaining until maintenance. (Press back switch (8) to return to the previous screen.)
3. Check the time remaining until maintenance. (a): Time remaining until maintenance (b): Default setting for maintenance interval When only checking the time remaining until maintenance, press back switch (8) twice. The screen will return to the normal operation monitor screen. When canceling time remaining until maintenance and returning to the default time setting, press inout confirmation switch (11). The screen will switch to the default setting screen.
3 - 25
