OPERATION
MACHINE OPERATIONS AND CONTROLS
Adjustment Seat Adjustment
WARNING When adjusting the position of the operator's seat, always set the lock lever to the LOCK position to prevent any accidental contact with the control levers.
Always adjust the operator's seat before starting each operation or when the operators change shift. Adjust the operator's seat so control levers and switches can be operated freely and easily with the operator's back against the backrest.
(A) Fore-and-aft adjustment Pull lever (1) up, set the seat to the desired position, then release the lever. Fore-and-aft adjustment: 160 mm (6.3 in) (16 stages) (B) Adjusting reclining NOTICE The operator's seat can be reclined to a large angle when the seat is completely pushed forward, but the reclining angle is reduced when the seat is moved backward. So return the seat to its upright position before moving the seat to the rear. Pull up lever (2) and set the backrest to a position that is comfortable for operation, then release the lever. Sit with your back against the seat backrest when adjusting. If your back is not against the backrest, the backrest may suddenly move forward.
3 - 81
