OPERATION
DETAILED CONTROLS AND GAUGES
FUSE NOTICE Before replacing a fuse, be sure to turn off the starting switch. The fuses protect the electrical equipment and wiring from burning out. If the fuse becomes corroded, or white powder can be seen, or the fuse is loose in the fuse holder, replace the fuse. Replace the fuse with another of the same capacity.
Fuse Capacities and Circuit Names No. (1)
Fuse capacity 10A Prolix circuit
Circuit
(2)
10A
Solenoid valve
(3)
10A
PPC hydraulic lock solenoid
(4)
20A
Window washer, cigarette lighter
(5)
10A
Horn, flash lamp light (if equipped)
(6)
10A
Auto greasing system (if equipped)
(7)
10A
Rotating lamp (if equipped)
(8)
10A
Spare
(9)
10A
Radio
(10)
10A
Spare
(11)
25A
Air conditioner unit
(12)
20A
VHMS (if equipped)
(13)
20A
Spare
(14)
10A
Optional power source (1)
(15)
10A
Optional power source (2), 12V power port
(16)
10A
Radio backup
(17)
10A
network pass (direct from battery)
(18)
20A
VHMS (if equipped)(direct from battery)
(19)
10A
Room lamp
(20)
10A
Step light
3 - 61
