50 DISASSEMBLY AND ASSEMBLY
REMOVE AND INSTALL DRIVER STATUS MONITOR
INSTALL DRIVER STATUS MONITOR 1.
Install the driver status monitor (3) to the bracket (2) with the screws (6) (4 pieces). REMARK • Install the driver status monitor (3) in the correct direction. • When you install it, be careful not to let the driver status monitor (3) stay outside the surface (a) of the bracket (2). Tool: Phillips screwdriver Screw (6): M4
2.
Connect the drowsiness detection camera cable connector (4) and connector DDS1 (5).
3.
Install the bracket (2) with the hexagonal socket head screws (1) (4 pieces). REMARK Be sure to put the washer. Tool: Torque wrench (hexagonal) Hexagonal socket head screw (1): Width across flats 4mm, M6 Hexagonal 9.8Nm{1.0kgfm}
50-8
socket
head
screw
(1):
HD785-7
