30 TESTING AND ADJUSTING
SET OPTIONAL SELECTION OF MACHINE MONITOR
ELECTRICAL SYSTEM SET OPTIONAL SELECTION OF MACHINE MONITOR Set the function of drowsiness detection system with “OPTIONAL SELECTION”. NOTICE • Make sure that the machine model selection is done before you set the optional selection. • Check all the items. 1. Set to the service menu selection screen. 1) Make sure that either of the "service meter, odometer setting", "action code", or "failure code" is shown on the character display.
2)
Do the operations that follow with the machine monitor mode selector switch. Switch operation: Press the switches (1) and (2) at the same time for 5 seconds or more. When the character display becomes blank, release the switches (1) and (2).
3)
When the ID input screen is shown, input the ID that follows with the machine monitor mode selector switch. ID: 6491 Switch (1): Moves the selection to the left end. And goes back to the operator mode screen if you press the switch twice. Switch (2): Decreases the selected number Switch (3): Validates the selected number Switch (4): Increases the selected number REMARK • If the ID input screen is left without switch operation for longer than 60 seconds, it automatically returns to the operator mode screen. • The inputted and validated ID will be effective until you turn the starting switch to the OFF position.
HD785-7
30-3
