SEN02017-00
50 Disassembly and assembly a
Installation q
Install the track roller assembly with the oil filler plug out. a After installing the track roller assembly, set the position of dowel pin (4). 2 Track roller assembly mounting bolt: Adhesive (LT-2) 3 Track roller assembly mounting bolt: 2,205 – 2,695 Nm {222 – 275 kgm}
Carry out installation in the reverse order to removal.
[*1] After removing tool L13, replace the mounting bolts of cover (3) with the regular parts. 3 Cover mounting bolt: 883 – 1,470 Nm {90 – 150 kgm}
[*3] [*2] Install S to the first and last track rollers and install D to the other track rollers. S: Single flange D: Double flange
14
When using the assembling tool Set tool L12 under the track roller assembly (2) and lift up and set track roller assembly (2) to the track frame.
D475A, D475ASD-5E0
