8001
Engine p.
48
CONNECTING RODS FIGURE 66
NOTE - Each connecting rod is marked on the body and cap with a number matching that of the cylinder in which it is to be fitted . If replacing the connecting rod , therefore, it is necessary to number the new one with the same number as the one it replaces.
15263
Check that axes of connecting rods are parallel. Permitted tolerance is 0.07 mm measured 125 mm from the longitudinal axis of the connecting rod . FIGURE 69
3987
Straightening a connecting rod stem (2) using a press (I).
15264
NOTE - Before fitting the connecting rod/piston assembly in the engine, check that it is square. It must be perfectly square; if not, trace the cause and change the parts concerned.
21187
Fitting bush (2) for connecting rod small end, using driver (I).
