ADJUSTMENT AFTER INSTALLATI0N
Dual Motors
Trim Tab Adjustment
1.
Single Motor
Remove the trim tab lock bolt and trim tab from the standard rotation outboard motor.
After the engine break-in, run the boat at full speed and check to see if the boat pulls to the left or right. Adjust the trim tab as required to ensure good and straight running characteristics. If the boat pulls to the left: Loosen the trim tab lock bolt, and move the trim tab trailing edge to the left.
TRIM TAB (Single motor use only)
//
Pulling to the right
TRIM TAB LOCK BOLT (10 x 32 mm HEX BOLT)
2. Replace the t r i m tab t o the gear case cover and tighten it with a trim tab lock bolt (10 x 32 m m hex bolt) as specified torque. TORQUE : 34 N.m (3.5 kgf-m, 25 IbfW
If the boat pulls to the right: Loosen the trim tab lock bolt, and move the trim tab trailing edge to the right.
43
