OPERATING CONTROLS AND PROCEDURES
TMS700E OPERATOR’S MANUAL
Engine Stop Indicator
Foot Throttle Pedal
The engine stop indicator (25) is located on the alert panel at the top of the right hand console. It is a red light that lights when energized by a signal from the engine ECM. When the light lights a buzzer also sounds.
The foot throttle pedal (4) is located on the right side of the cab floor. The pedal sends an electronic signal to control engine speed.
Engine Warning Indicator The engine warning indicator (48) will light to alert the operator of a temperature high, a pressure low, or a coolant level low condition.
1 Outrigger Control Box
2
3
1 24
4
Front Console
23
5
22
6
21
8 7 9 20
Overhead Console
19 18
10
17
11
16
15 12
14
FIGURE 3-3 13
3-12
Published3-13-2013, Control # 433-01
