LUBRICATION
TMS700E OPERATORS MANUAL 18. Front Rear Axle Differential
Item
Lube Type - SSGL-5
Description
Lube Interval - Check lubricant level every 250 hours and refill as necessary. Drain, fill, change filter, and clean magnetic drain plug every 80,000 km (50,000 mi) or 2 years, whichever interval occurs first.
1
Engine Crankcase
2
Engine Cooling System
3
Transmission
4
Pump Drive
5
Pump Drive Shaft U-Joints and Spline
Lube Amount - Capacity - 27 liters (57 pints) Normal makeup - less than 0.23 liter (0.5 pint)
6
Clutch Throw Out Bearing
Application - Fill to bottom of fill plug threads.
7
Clutch Linkage
8
Transmission Shift U-Joints and Control Unit
9
Power Steering Gearbox
10
Steering Relay Arms
11
Front Aluminum Wheel Pilots
12
Front Axle Hubs
13
Front Axle Tie Rod Ends
14
Front Axle King Pins
15
Front Axle Brake Slack Adjusters
16
Front Axle Brake Camshafts
17
Rear Aluminum Wheel Pilot
18
Front Rear Axle Differential
19
Rear Rear Axle Differential
20
Rear Axle Brake Slack Adjusters
21
Rear Axle Brake Camshafts
22
Outrigger Beams
23
Jack Cylinder Support Tubes
24
Jack Cylinder Barrels
25
Hydraulic Reservoir
26
Hydraulic Filter
27
Fuel Filter
28
Air Cleaner
29
Coolant Strainer (Superstructure Cab Heater)
30
Fuel Filter
Use of non-semi-synthetic lubricant may damage components and/or invalidate published lubrication intervals. If the makeup amount is substantially more than 0.23 liter (0.5 pint) check for leaks. NOTE:
Lube level (Figure 5-2) close enough to the hole to be seen or touched is not sufficient. It must be level with the hole. When checking lube level, also check and clean housing breathers.
___ Correct: Lube level at bottom of filler hole. - - - Incorrect: Lube level below filler hole.
FIGURE 5-2 NOTE:
Figure 5-2 pertains to the differentials and the planetary hubs and wheel bearings.
19. Rear Rear Axle Differential Lube Type - SSGL-5
CAUTION Axle fluid levels shall be adjusted to bottom of fill plug threads. Check with crane on level ground, at its normal ride height; cold or room temperature oil only.
5-8
CAUTION
Lube Interval - Check lubricant level every 250 hours and refill as necessary. Drain, refill, and clean magnetic drain plug every 80,000 km (50,000 mi) or 2 years, whichever interval occurs first.
Published 2-20-2012, Control # 433-00
