LUBRICATION
TMS700E OPERATORS MANUAL
rust has not formed, otherwise the component must be cleaned first. Grease fittings that are worn and will not hold the grease gun, or those that have a stuck check ball, must be replaced.
Where wear pads are used, cycle the components and relubricate to ensure complete lubrication of the entire wear area. Table 5-1 Lube Symbol Chart
Symbol
Description
AFC
Antifreeze/Coolant - 50/50 Blended, Fully Formulated - SAE Grade J1941
EO
Engine Oil - SAE 15W-40, API Service Classification CJ-4. (CI-4 for pre-2007 ISM engines)
EP-MPG
Extreme Pressure Multipurpose Grease - Lithium Soap Base, NLGI Grade 2.
SGL-5
Synthetic Gear Lubricant - SAE Grade 50, API Gravity 23.
HYDO
Hydraulic Oil - Must meet John Deere Standard JDM-J20C, Allison C4, and ISO 4406 level.
SSGL-5
Semi-Synthetic Gear Lubricant - SAE Grade 80W-90, API Service Designation GL-5.
ASC
Anti-Seize Compound - Military Specifications MIL-A-907E.
EP-OGL
Open Gear Lubricant - Fucs Ceplattyn 300 Spray, NLGI Class 1-2
EPGL-5H
Extreme Pressure Gear Lubricant - SAE Grade 80W-140
SCA
Supplemental Coolant Additive
Table 5-2 Lube Description Lubrication Description
Lube Specification
50/50 Fully Formulated Anti-Freeze Coolant
6829101130
Engine Oil SAE 15W40, CJ4
6829104182
Engine Oil SAE 15W40, CI4
6829003483
Extreme Pressure Multi-Purpose Grease
6829003477
Synthetic Gear Lube
6829013433
Hydraulic Oil
6829006444
Semi-Synthetic Gear Lube
6829012964
Anti-Seize Compound
6829003689
Open Gear Lube
6829102971
EPGL Gear Lube
6829006240
Supplemental Coolant Additive
6829012858
Wire Rope
See Service Manual
The following describe the lubrication points and gives the lube type, lube interval, lube amount, and application of each. Each lubrication point is numbered, and this number corresponds to the index number shown on the Lubrication Chart (refer to Figure 5-1 through 5-3, Table 5-1 and Table 52).
5-4
CAUTION The following lube intervals are to be used as a guideline only. Actual lube intervals should be formulated by the operator to correspond according to conditions such as continuous duty cycles and/or hazardous environments.
Published 2-20-2012, Control # 433-00
