Swing-away lattice 4.3 Checklists for rigging work
18. Install the anemometer and if necessary establish an electrical connection for the air traffic control light; Installing/removing the anemometer, p. 4 - 83, Air traffic control light – electrical connection, p. 4 - 85.
à à
19. Install the lifting limit switch; switch, p. 4 - 80.
à Installing/removing the lifting limit
20. In the case of the inclinable swing-away lattice, adjust the angle, if necessary; Setting the angle – with the auxiliary crane, p. 4 - 91. Setting the angle – without the auxiliary crane, p. 4 - 92.
à à
21. Reeve the hoist rope on the hook block; the swing-away lattice, p. 4 - 79.
à Possible reeving methods on
22. Attach the lifting limit switch weight and place it around the hoist rope; Operating instructions GMK 5130-2/5110-1, section 2 Superstructure – Rigging work.
à
21.08.2008
23. Check the horizontal alignment of the truck crane and correct, if necessary.
4 - 18
3 112 518 en
Operating instructions lattice extension GMK 5130-2/5110-1
