Auxiliary single-sheave boom top 6.1 Installing/removing
6
Auxiliary single-sheave boom top
6.1
Installing/removing
6.1.1
Installing/removing the auxiliary single-sheave boom top
Support
• (A) – Sling the auxiliary single-sheave boom top;
à p. 3 - 12.
• Pull out the pin (1). • Hoist the auxiliary single-sheave boom top in front of the clamp.
• Align the auxiliary single-sheave boom top so that the bearing point lines up to the front bore holes in the clamp.
• (B) – Insert the pin (1) and secure it with a linch pin.
• Move the auxiliary single-sheave boom top into the transport position or working position; Rigging the auxiliary single-sheave boom top, p. 6 - 3.
à
