Swing-away lattice 4.4 Description of rigging work
The button (1) is only active if the derricking swing-away lattice is electrically connected.
• Press the button (1) – the engine will now start.
Pre-select derricking swing-away lattice
• Press the button (1). – Indicator lamp in key lights up. Lifting/lowering swing-away lattice
• Press the button combination for the desired movement: 1 Raise swing-away lattice 2 Lower swing-away lattice The further in you press the button (1) or (2), the faster the movement.
21.08.2008
The pre-selected movement is executed until you let go of the respective button or until the respective end position has been reached.
