Swing-away lattice 4.4 Description of rigging work
On the 18 m (59 ft) swing-away lattice Connecting the lifting limit switch
• Fit the lifting limit switch (3) on to the clamp (2) and secure it with a retaining pin.
• Lay the connecting cable (4) in such a way that it will not be damaged during crane operation, and connect the lifting limit switch to the socket (1). For operation with the 18 m (59 ft) swing-away lattice, the connection for the lifting limit switch must be overridden at the 11 m (36 ft) swing-away lattice with the short-circuit plug.
Removing the lifting limit switch
• Pull the plug from the socket (1). • Remove the lifting limit switch (3) from the clamp (2).
• Fasten the retaining pin to the lifting limit
