ISO-Style (Used Internationally) Safety and Information Decals

Note: Refer to Figure 2 on page16 for decal locations.

A

Located on the front panel below the door, behind the attachment hitch.

DANGER: AVOID INJURY OR DEATH a.Keep out from under work tool, unless lift arm is supported. b.No riders! Never use work tool as work platform.

Located on the inside of the right lift arm pillar.

WARNING: AVOID INJURY OR DEATH a.Safety alert / Keep safety devices in place and in working order. b.Fire hazard / Do not smoke while fueling or servicing the machine. Clean debris from the engine compartment to avoid fires. Keep fire extinguisher nearby. c.Run-over hazard / Jump-start the machine only according to the operator’s manual. See “Jumpstarting” on page60. d.Oil injection hazard / Do not use hands to find hydraulic leaks. Escaping oil under pressure can penetrate skin. Use a piece of cardboard to find leaks. e.Burn hazard / Allow radiator to cool before removing cap. Loosen cap slowly to avoid burns. f.Suffocation hazard / Operate only in a well-ventilated area.

C Located next to the fuel filler neck. USE PROPER DIESEL FUEL ONLY!

D

Located on the bottom of the side panels behind the rear wheels (both sides), and on the bottom outside corners of the front panel (both sides).

•Tie-down point. Only use tie-down points indicated on machine when transporting machine. E Located on the interior surface of the rear window in the lower left corner. Designates emergency egress location.

Note: Refer to Figure 2 on page16 for decal locations.

Located on the side of the ROPS/FOPS.

WARNING: Crush Hazard

•Be sure lock mechanism is securely engaged before working under ROPS/FOPS. Read instructions for use in Operator’s Manual.

USE PROPER HYDRAULIC FLUID ONLY!

Located near the hydraulic fluid reservoir filler neck.

Located inside the engine compartment.

WARNING: ROTATING FAN

•Keep hands out or stop engine.

Located on the left door pillar, facing the operator.

DANGER: AVOID INJURY OR DEATH

WARNING: AVOID OVERTURN a.Forward tip hazard: Carry load low, do not exceed Rated Operating Load. b.Fasten seat belt. c.Side tip hazard: Avoid steep slopes and high-speed turns. Travel up and down slopes with heavy end uphill. d.Crush hazard: Keep out from under lift arm unless lift arm is supported. Keep hands, feet and body inside cab when operating.

Note: Refer to Figure 2 on page16 for decal locations.

Located on the right door pillar, facing the operator.

DANGER: AVOID INJURY OR DEATH a.Crush hazard: Keep out from under lift arm unless lift arm is supported. b.Crush hazard: Hose removal or component failure can cause lift arm to drop. Always use lift arm support device when leaving lift arm raised for service. c.Side tip hazard: Avoid steep slopes and high-speed turns. Travel up and down slopes with heavy end uphill. d.Crush hazard: Keep hands, feet and body inside cab when operating.

Located inside the engine compartment.

WARNING: HOT SURFACE

•Do not touch hot engine or hydraulic system parts.

Located on the left door pillar, facing the operator.

WARNING: AVOID INJURY OR DEATH

Always follow “Mandatory Safety Shutdown Procedure.”

•1) Lower equipment to ground.

•2) Reduce throttle, stop engine.

•3) Apply brake; remove key.

•4) Check safety interlocks.

Note: Refer to Figure 2 on page16 for decal locations.

Safety Alert

a.Check machine before operation according to Operational Checks starting on page55. Contact dealer (or manufacturer) for information and service parts.

b.Maintain 3-point contact during entry and exit.

c.Inspect work area. Avoid all hazards. Look in direction of travel. Keep children and bystanders away.

d.Start and operate machine only from the operator’s position with the seatbelt fastened.

e.Keep away from power lines; avoid contact.

f.Wear any needed Personal Protective Equipment. Do not wear loose clothing while operating or servicing machine.

Located on the bottom of the ROPS/FOPS operator enclosure.

WARNING: Crush Hazard

•Be sure lock mechanism is securely engaged before working under ROPS/ FOPS.

•Read instructions for use in Operator’s Manual.

Located behind the operator’s seat above rear window

WARNING: AVOID INJURY OR DEATH

•Read Operator’s Manual and all safety signs before using machine.

•The owner is responsible to ensure all users are instructed on safe use and maintenance.

•Check machine before operating; Service per Operator’s Manual.

•Contact dealer (or manufacturer) for information and service parts.

Note: Refer to Figure 2 on page16 for decal locations.

Located on the front of the lift arm cross-member.

WARNING: AVOID INJURY OR DEATH

•Before operating with attachment, check engagement of loader attachment bracket locking pin to the attachment.

DANGER

•Hose removal or component failure can cause lift arm to drop. Always use lift arm support device when leaving lift arm raised for service.
