A - DAILY OR EVERY 10 HOURS OF SERVICE
-
Visually check that there are no leakage from the radiator and hoses.
WARNING
A1 - ENGINE OIL LEVEL
To avoid the risk of spraying and scalding, wait until the engine has cooled down before removing the cooling system filler plug. If the coolant is very hot, add only hot coolant 176°F (80°C). In an emergency, you can use water as a coolant, and then change the coolant as soon as possible (see chapter: 6 - MAINTENANCE: F1 - COOLANT).
CHECK Park the telescopic handler on level ground with the engine stopped, and let the oil drain into the oil pan. -
Open the engine cover.
-
Remove the dipstick (1) (fig. A1).
-
Wipe the dipstick and check for the correct level at the upper mark.
-
-
A3 - FUEL LEVEL CHECK
If necessary, add oil (see chapter: 6 MAINTENANCE: LUBRICANTS AND FUEL) at the filler port (2) (fig. A1).
Keep the fuel tank full, to reduce condensation due to atmospheric humidity. -
Remove cap (1) (fig. A3).
-
Fill the fuel tank with clean fuel (see chapter: 6 MAINTENANCE: LUBRICANTS AND FUEL ), filtered through a strainer or a clean, lint-free cloth, through the filler neck (2) (fig. A3).
-
Replace the cap (1) (fig. A3).
-
Visually check that there is no leakage from the tank and hoses.
Visually check that there is no leakage of oil from the engine.
A2 - ENGINE COOLANT LEVEL CHECK Park the telescopic handler on level ground with the engine stopped, and allow the engine to cool. -
Open the engine cover.
-
Check the correct level in the middle of sight gauge (1) (fig. A2/1).
-
If necessary, add coolant (see chapter: 6 - MAINTENANCE: LUBRICANTS AND FUEL).
-
Slowly turn the cap of the radiator (2) (fig. A2/1) counter-clockwise to the safety stop.
-
Allow the pressure and vapor to escape.
Never smoke or have an open flame nearby during filling operations or when the tank is open.
-
Press down and turn the cap to release the cap.
Never refuel while the engine is running.
-
Add coolant at the filler neck (3) (fig. A2/1) up to the middle of sight gauge (1) (fig. A2/1).
-
WARNING
IMPORTANT: The fuel tank is vented through the filler cap. When changing it, always use an original part, with a vent.
Lubricate the filler neck slightly to ease closing and opening of the radiator cap.
