LUBRICANTS AND FUEL SYSTEM/COMPONENT
CAPACITY
RECOMMENDED
CRANKCASE
2.9 gal. (11 liters)
API CH-4
COOLING SYSTEM
4.9 gal. (18.5 liters)
Ethylene Glycol/Water Solution (protection -30° F)
FUEL TANK
31.7 gal. (120 liters)
Diesel Fuel (*)
TRANSMISSION
4.1 gal. (15.5 liters)
Automatic Transmission Fluid
ANGLE GEAR BOX
2.25 qts. (2.2 liters)
API GL5 80W90
ENGINE
TRANS. UNIVERSAL JOINT
No. 2 Lithium-Based Grease
BOOM WEAR PADS
No. 2 Lithium-Based Grease
GREASING THE BOOM
No. 2 Lithium-Based Grease
HYDRAULIC SYSTEM HYDRAULIC OIL RESERVOIR
33 gal. (125 liters)
Hydraulic ISO VG46 (Mobil DTE 15 M or equal)
BRAKE SYSTEM BRAKE CIRCUIT
ATF Dexron II
CAB CAB DOOR
No. 2 Lithium-Based Grease
WINDSHIELD WASHER RESERVOIR
Windshield Washer Fluid
FRONT AXLE DIFFERENTIAL
7.7 qts. (7.3 liters)
API GL5 SAE 85W90
REAR AXLE DIFFERENTIAL
7.8 qts. (7.4 liters)
API GL5 SAE 85W90
FRONT WHEEL PLANETARIES
0.80 qts. (0.75 liters)
API GL5 SAE 85W90
REAR WHEEL PLANETARIES
1.50 pts. (0.75 liters)
API GL5 SAE 85W90
FRONT AND REAR WHEEL STEERING SPINDLES
No. 2 Lithium-Based Grease
REAR AXLE OSCILLATION
No. 2 Lithium-Based Grease (*) FUEL CHARACTERISTICS
IMPORTANT: Use only the recommended lubricants and fuel.
Use a high-quality diesel fuel to obtain optimal performance of the engine.
NOTE: For topping up, all oils may not be compatible.
