SERVICE LUBRICATION
E
F
Outer side bearing support
G L
H D
I
Greasing and lubricant points
OIL QUANTITY: lt
D) Rotor spindle lubricator E) Reduction unit oil plug F) Transmission oil fill plug G) Transmission oil level plug H) Transmission oil drain plug I) Hoe blades fixing bolts L) Outer side bearing support fill and level plugs
(US gal.)
1173 1181
1273
Reduction unit oil - E
1(0.25) 1.25(0.3)
Transmission oil fill gears - F
2(0.5)
3 (0.8)
Outer side bear. support - L
0.18 (0.05)
0.18 (0.05)
2283
2293
3(0.8)
4.5(1.2)
4.25 (1.1) 0.18 (0.05)
4.25 (1.1) 0.18 (0.05)
Lubricants
• It is advisable to use SAE 85W/140 OIL or equivalent for the reduction unit (or gear box) and side transmission. • It is advisable to use GR MU EP 2 GREASE or equivalent for all greasing points.
Bolts tightening torques - settings given in Nm (lb-ft) CLASS
Fine pitch screws 6.6
8.8
10.9
12.9
M8 x 1
15 (11)
26 (19)
36 (26.5)
44 (32.5)
M10 x 1.25 M12 x 1.25 M14 x 1.5 M16 x 1.5 M18 x 1.5 M20 x 1.5 M22 x 1.5 M24 x 2 M27 x 2 M30 x 2
30 (22) 51 (37.5) 81 (60) 120 (88) 173 (127) 242 (178) 321 (237) 411 (303) 601 (443) 832 (614)
52 (38) 91 (67) 143 (105) 214 (158) 308 (227) 431 (318) 571 (421) 731 (539) 1070 (790) 1480 (1090)
74 (54) 127 (94) 201 (148) 301 (222) 433 (319) 606 (447) 803 (592) 1028 (758) 1504 (1110) 2081 (1535)
88 (65) 153 (113) 241 (178) 361 (266) 520 (384) 727 (536) 964 (711) 1234 (910) 1806 (1333) 2498 (1843)
Service Lubrication - Page 23
