INSTALLATION DETACHING EQUIPMENT (GLOBAL CARRIER SERIES LOADERS)
NOTE: If using optional parking stands, completely close grapple clamps. Always place unit on a solid level surface. NOTE: If unit is not equipped with optional parking stands, open grapple clamp arms completely. NOTE: Disconnect hydraulic attachments before backing away.
1. Position the attachment with the main frame about vertical. 2. Place the transmission in PARK and shut off engine and remove key. 3. Pull and rotate handle to open latch (A). 4A. DETACHING (without Parking Stands) Start tractor and extend bucket tilt cylinders to roll root grapple forward. When tips of grapple clamps and points of main frame are about level with ground, lower loader boom until attachment is on ground. Extend bucket cylinders until loader clears latch plate and bar is free from hooks. 4B. DETACHING (with Parking Stands) Lower parking stands and pin in position. Start tractor and lower attachment to ground. Slowly extend bucket tilt cylinders until loader clears the latch plate. Lower loader until bar clears the hooks. 5. Drive tractor in reverse until loader is clear of the attachment.
Installation 15
