INSTALLATION ATTACHING EQUIPMENT (600 & 700 SERIES LOADERS WITH QUIK-CHANGE LATCHES)
(Root Grapple equipped with optional parking stands) 1. Extend attachment cylinders to angle attaching brackets forward. 2. 600/700 - Drive forward, adjusting loader height and position until the top of the bracket is aligned with the pins (A).
700 SERIES
3. Raise loader to engage hooks and retract attachment cylinders quickly. 4. 600/700 - Raise loader until you can check that pins (D) on both sides have fully dropped. 700 SERIES BOLT-ON LATCH SHOWN
5. Lower attachment, shut off engine and remove key. Connect hydraulic hoses to the auxiliary hydraulic hook up on your loader or to rear tractor remote outlets. Pin the parking stands in the raised position.
DETACHING EQUIPMENT (600 & 700 SERIES LOADERS WITH QUIK-CHANGE LATCHES) NOTE: If using optional parking stands, completely close grapple clamps. Always place unit on a solid level surface. NOTE: If unit is not equipped with optional parking stands, open grapple clamp arms completely. NOTE: Disconnect hydraulic attachments before backing away. 1. Position the attachment with the main frame about vertical. Place the transmission in PARK and shut off engine and remove key. 2. Lift and rotate latches (A) up on both sides of attachment. 3A. DETACHING (without Parking Stands) Start tractor and extend bucket tilt cylinders to roll root grapple forward. When tips of grapple clamps and points of main frame are about level with ground, lower loader boom until attachment is on ground. Extend bucket cylinders until loader brackets clear latch pin pockets and holder is free from top pins. 3B. DETACHING (with Parking Stands) Lower parking stands and pin in position. Start tractor and lower attachment to ground. Slowly extend bucket tilt cylinders until loader brackets clear the latch pin pockets. Lower loader until holder clears the pins. 4. Drive tractor in reverse until loader is clear of the attachment.
Installation 13
