OPTIONAL EQUIPMENT SINGLE TAILWHEEL KIT 5WP1001533
Attach tailwheel tube assembly (1) to rear of tilt turntable and secure with cap screws (5) and hardened flat washers (4) from turntable. Torque cap screws to 170 lbs-ft. (231 N-m).
Assemble Tailwheel (Figure 10)
NOTICE Floating links must be used with tailwheel to avoid equipment damage. Tailwheel kit will not function properly when used with Quick Hitch. Remove round retainer plate and hardware from rear of tilt turntable of rear blade (refer to Figure 5). NOTE: Point drop pins in tilt turntable towards center of unit (Figure 11) before attaching tailwheel tube assembly.
1. Tailwheel tube assembly 2. Notat yoke assembly 3. 3/8" Spirol pin 4. 5/8" Hardened flat washer (from turntable) 5. 5/8 NF x 1-1/2" Cap screw (from turntable) Figure 10. Tailwheel Assembly
Attach yoke assembly (2) to tailwheel tube and secure into position with spirol pin (3).
Assemble Floating Link (Figure 12) Attach right and left floating link brackets (14, 15) with offset to the inside on each side of the A-frame. Place sleeve (16) in forward hole and secure assembly into position using two cap screws (18) and lock nuts (19) as shown in Figure 12. NOTE: When attaching to tractor, install clevis pin (17) into floating links using two 3/4" washers (20), one cotter pin (21), and hair pin (22) as shown.
14. 15. 16. 17. 18. 19. 20. 21. 22.
Right floating link Left floating link Sleeve .78 x 1.00 x 2.00" Clevis pin .75 x 4.38" 3/4 NC x 4-1/2" Cap screw GR5 3/4" NC Lock nut 3/4" Flat washer 3/16 x 1-1/2" Cotter pin 5/32" Hair pin cotter Figure 12. Floating Link Installation
Adjust Tailwheel Assembly
Figure 11. Drop Pin Position 5WPMAN0148 (Rev. 5/16/2008)
Set blade cutting edge 1/2" (13 mm) above the ground with the tractor 3-point hitch. Adjust tail wheel until tire is on the ground and the top link pin is centered in the floating link slot. Fine tune the grading height by raising or lowering the 3-point hitch.
Optional Equipment 13
