TORQUE RECOMMENDATIONS—
YOKE LOCKSCREWS, 35·45 Ft.·Lbs., 7/16·20 Threads, Secure with Lock Wire.
~
_
RANGE SHIFT YOKE CAPSCREWS, 50-65 Ft.·Lbs., 112-20 Threads, Secure with Lock Wire. \
~k~~-~L~:.~~g~-~f ~hreads.
AUXILIARY RANGE SHIFT
\
SHIFT BAR HOUSING CAPSCREWS, 35·45 Ft.·Lbs., 3/8-16 Threads Apply Loctite 242 to threads.
~;.~~N~~~b;.~~,~~i~~~~;;ws,
\
~
\
\
REVERSE SIGNAL SWITCH PLUG, 35·50 Ft.·Lbs., 9/16·18 Threads. STUDS \ 60 Ft.·Lbs. Minimum, Driven Until Bottomed, 5/8·11 Thread, Installed with Fuller No. 71204 Sealant. 1
L......1
1
CLUTCH HOUSING NUTS,
Apply Loctite 242 to threads. \.
~\
1
1
AUXILIARY DRIVE GEAR RETAINER
\
RANGE CYLINDER SHIFT BAR
70-85 Ft.·Lbs., 5/8·18 Threads with \~NUT, Nylon Locking Patch.
~AIR FILTER/REGULATOR CAPSCREWS,
\
8-12 Ft.·Lbs., 1/4-20 Threads. Apply Loctite 242 to threads. \ REAR BEARING COVER CAPSCREWS 35.45 Ft.·Lbs.: 3/8·16 Threads.
~
~
~ ~t::.o-2oo~I\
\
~""~Apply Loctite 242 to threads.
~
I
f
1
CLUTCH HOUSING CAPSCREWS, 1/2-13 Threads, 80-100 Ft.-Lbs., Use Lockwashers. FRONT BEARING COVER CAPSCREWS, 35.45 Ft.-Lbs., 3/8-16 Threads. Apply Loctite 242 to threads.
REVERSE IDLER SHAFT NUTS. 50-60 Ft.-Lbs., 5/8-18 Threads with Nylon Locking Insert.
(
INTERMEDIATE SHIFT YOKE LOCKSCREW, 35·45 Ft.·Lbs., 7/16·20 Threads, Secure with Lock Wire.
AUXILIARY RANGE SHIFT CYLINDER CAPSCREWS, 35·45 Ft.·Lbs., 3/8·16 Threads, Apply Loctite 242 to threads.
7190 B-6/86
12
