REASSEMBLY - COMPANION FLANGE AND CLUTCH HOUSING Companion Flange and Clutch Housing A. Installation of the Clutch Housing
2. Install the washers and nuts on the studs and then install the washers and bolts, using correct torque: See TORQUE RECOMMENDATIONS.
1. Install the clutch housing on the studs in the front case.
B. Installation of the Companion Flange or Yoke
1. Install the speedometer drive gear or replacement spacer on the hub of the yoke or flange, lock the transmission by shifting the front section into two gears and install the yoke or flange on the splines of the tailshaft. Install the tailshaft nut and torque to 450-500 ft./lbs.
101
