Bucket Cylinder of 450 Series
IGAT141l
1. Place the bucket cylinder in a vice and remove the rod cover (3).
6. Remove the bushing (19) from the knuckle and head cover.
2. Remove rod assembly (2) from the cylinder assembly.
7. Assemble the bucket cylinder in the reverse order of disassembly.
3. Remove spring pin (18), hex nut (17), piston (12) and rod cover (3) from the rod assembly. 4. Remove cushion ring (11), O-ring (13), dust ring (14), slipper seal (15) and wear ring (16) from the piston. 5. Remove dust wiper (4), back up ring (6), U-packing (5), washer (10), DU bush (7), back up ring (9) and O-ring (8) from the rod cover.
Hydraulic & Hydrostatic Systems
49
Disassembly & Assembly
