4 - ASSEMBLY
30. Working from inside the cab, remove the plug (R) on the front left-hand instrument panel (S) . 31. Loosen and remove the fastening screws (T). 32. Paying attention to the electric connections, partially lift the front left-hand instrument panel (S) to make the lower side accessible.
RAIL14TLB0878BA
16
RAIL14TLB0879BA
17
RAIL14TLB0880BA
18
RAIL14TLB0883BA
19
33. Remove the screws fastening (U) of the side instrument (V). NOTICE: Care must be used when pulling the panel away from the cluster so that there is no damage to the wire harnesses.
34. Working under the instrument, first install the plate (19) , then mount the buzzer (20) on it. 35. Connect the wiring harness (21) to the buzzer (20).
36. Remove the fuse cover by loosing the cover screws and pulling off the cover. 37. Connect the wiring harness (21). 38. Install the fuse cover.
12 EN
