5 - ASSEMBLY
5 - ASSEMBLY Install
Joystick steering 1. Install the straight connector (9) on the LS port of the EHPS steering valve (3). 2. Install the 90° elbow (10) on the T port of the EHPS steering valve (3). 3. Install the 90° elbow (11) on the P port of the EHPS steering valve (3). 4. Install the 90° elbow (42) on the PS port of the EHPS steering valve (3).
LEIL19WHL0496BB
1
14 EN
