CNH Joystick Steering Kit Standard Hydraulic Steering 721G W170D Wheel Loader Instructions Manual

4 - PRE-ASSEMBLY

10. Locate the right-hand steering cylinder area. Remove the clamp (C), and the block (D).

11. Disconnect and remove the hose (F) from the union tee (G) and then from elbow (E).

12. Disconnect and remove the hose (H) from the union tee (L) and from the right-hand cylinder tube (M).

13. Discard the hoses (F) and (H).
