2 - KIT CONTENT
2 - KIT CONTENT Kit overview NOTICE: to check the items part numbers of this kit, please refer to the Parts Catalogue. NOTE: the following table shows the items numbered as in the installation instruction. Item 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48 49
Description JSS valve mounting bracket EHPS steering valve JSS cut-off valve 45° elbow 90° elbow 90° elbow Straight connector Straight connector Shuttle tee 45° elbow Washer 9x21x2.5 mm Bolt M8x20 Swivel run union tee Hose (to steering cylinder) 1054 mm (41.5 in) Hose (to steering cylinder) 1128 mm (44.4 in) Swivel branch tee Washer 13.5x28x4 mm Nut M12 Bolt M12x50 Right-hand steering cylinder head tube 36.2 mm (1.4 in) Block clamp Hose clamp Right-hand rod hose 435 mm (17.1 in) Right-hand base hose 545 mm (21.4 in) JSS load sense hose 922 mm (36.3 in) Hose (to tank) 894 mm (35.2 in) JSS pressure hose 880 mm (34.6 in) Steering load sense hose 900 mm (35.4 in) Cable tie JSS sensor mounting bracket Washer 9x16x1.6 mm Bolt M8x10 Steering angle sensor Nut M10 Steering pump isolator Rubber bushing Steel bushing Lock washer M10x22 Bolt M10x30 O-ring Washer 11x21x2.5 mm Bolt M10x105 90° elbow Hose (cut-off valve to tank) 965 mm (38 in) 90° elbow Joystick steering tube 203.1 mm (8 in) Plug Washer 10.6x25x6 mm
Quantity 1 1 1 2 1 1 1 2 1 1 3 3 3 1 1 1 6 3 3 1 1 1 1 1 1 1 1 1 17 1 7 4 1 3 1 4 4 4 4 1 6 6 1 1 1 1 2 2
5 EN
