Measurement and control Checking the oil pressure Test conditions : – Engine running idle, empty. – Oil temperature at 93°C.
HYDRO TESTER
101hsm52
Fig. 57
– Connect a hydraulic fitting (1/8 – 16 x 200) onto the pressure tap. – Connect test set n° 0178 310.0. The minimum oil pressure must be 1,05 bar.
A1.68
Arion 640-510 – 06.2008 – GB
