04 Brakes 04 15 Handbrake
Adjusting the control lever – Maintain the pin (15) and the cam in braking position. – Release the rod (G) by disconnecting the control cable (F). – Apply a force of 10 daN with a weight indicator connected to the rod end and position it so as to obtain a dimension of 270 mm between the cable attachment (E) and the rod axis. Remove and install successively the rod to obtain a dimension of 270 mm. – Connect the control cable (F). – Tighten the locknut (A) on the washer (B). Note: For a good aligning of the sheath stop (D) and the cable (F), the nut (C) and the locknut (A) must be mounted at the front of the attachment bracket (E). – Check operation of the control. – Tighten the lever, the braking initial stroke should be around 8 notches. The instrument panel indicator must light first in handbrake locked position.
362msm49
Fig. 14
362msm51
Fig. 15
– Release the lever, the control must return freely to the idle position. In this position, the indicator must switch off.
