02 Transmission/clutch Electro-hydraulic PTO
Measurements and checks Checking the front axle engagement pressure (4 wheel drive) Test conditions: – Tractor secured on props. – Engine running at 2 200 rpm. – Transmission oil temperature: 60°C.
HYDRO TESTER
Fig. 38
a2102002
– Fit the pressure sensor of kit No.00 0178 310 0 on a T fitted with hoses on the level of the supply of the 4 wheel drive unit. – Press button "S1". The measured pressure must be 21 bar.
60
Arion 430-410 – 12.2009 – GB
