02 Transmission/clutch Differential
Measurements and checks Control of differential locking engaging pressure Test conditions: – Engine running at 2 200 rpm. – Transmission oil temperature: 60°C.
HYDRO TESTER
Fig. 37
a2102001
– Fit the pressure sensor of kit No.00 0178 310 0 on a T fitted with hoses on the level of the differential lock supply. – Connect tester Nr.00 0178 310 0 to the pressure sensor. – Actuate the contact of the "S94" differential lock. – Measure the pressure which must be 20,5 bar.
56
Arion 430-410 – 12.2009 – GB
