02 Transmission/clutch Lubrication
Checking the lubrication flow of the upper range shaft and forward drive clutch Test conditions: – Engine running at 2 200 rpm. – Transmission oil temperature: 60°C. – Transmission engaged (tractor made safe on stands). – No actuator activated (spool valves, steeering, PTO, etc.). – Remove the tubing (1) between the lubrication leader and the tee. – Connect the tester of the kit n°00 0178 310 0 and n°00 0178 320 0.
HYDRO TESTER
1 Fig. 33
395msm1j
The flow rate should be about 18 l/min. This flow rate is given in l/min for information.
44
Arion 430-410 – 12.2009 – GB
