02 Transmission/clutch Lubrication
Checking the lubrication flow of the "Revershift" clutch and the "Quadrishift" set Test conditions: – Engine running at 2 200 rpm. – Transmission oil temperature: 60°C. – Transmission engaged (tractor made safe on stands). – No actuator activated (spool valves, steeering, PTO, etc.). – Remove the tubing (1) between the lubrication leader and the elbow. – Connect the tester of the kit n°00 0178 310 0 and n°00 0178 320 0.
HYDRO TESTER
1
Fig. 31
b2000
The flow rate should be about 20 l/min. This flow rate is given in l/min for information.
42
Arion 430-410 – 12.2009 – GB
