08 Power and control outputs Rear power take-off
Rear power take-off Measurements and checks Checking supply pressure of the rear PTO clutch Test conditions: – Engine running at 2 200 rpm. – Transmission oil temperature: 60°C.
9010
HYDRO TESTER
Fig. 4
a2108001
– Fit the pressure sensor of the 00 0178 310 0 kit onto the low pressure connector "9010". – Connect tester Nr.00 0178 310 0 to the pressure sensor. – Start the tractor, engine speed at 2 200 rev/min. – Actuate the on/off contact of the "S114" rear power take-off. – Pressure must stabilize at 21 bars.
Arion 430-410 – 10.2009 – GB
9
