5.1.2
Hoist points
Figure 36 below indicates the correct hoist points for hoisting the truck up for maintenance. Make sure that the capacity of the lifting device is sufficient.
Figure 36. Hoist points
5.2
Transportation
When transporting the truck, it is important that you secure it safely to prevent it from moving. Also support the traction wheel with blocks and lower the mast. If the truck is equipped with an operator’s platform, lift the operator’s platform up. Figure 37 below shows an example on how to secure the truck safely for transportation.
